Electrobombas de superficie12 Voltios SERIE TMC-6010101

bombas de agua de 12V

Amplia gama-los mejores precios de bombas de agua de 12V Bombas de corriente continua autoaspirantes Diseñadas para trasegar caudales discretos aguas limpias libres de sólidos. preparadas para arranque automático. a través de presostato.

TMC-06201
Water pump
MOTOR :12V / 24V
CAPACITY :400GPH (1512LPH)
AMP DRAW :8A (12V) / 4A (24V)
FUSE SIZE :15A (12V) / 8A (24V)
HOSE DIA. :1 (25mm)
DELIVERY HEAD :13FT. (4M)
DIMENSION :168.6x120x97.1 mm

TMC-06202
Water Pumps
Description Water pump with pressure switch
MOTOR :12V / 24V
CAPACITY :400GPH (1512LPH)
AMP DRAW :8A (12V) / 4A (24V)
FUSE SIZE :15A (12V) / 8A (24V)
HOSE DIA. :1 (25mm)
DELIVERY HEAD :13FT. (4M)
DIMENSION :168.6x201x97.1 mm

TMC-06203
Water Pumps
Description Water pump
MOTOR :12V / 24V
CAPACITY :400GPH (1512LPH)
AMP DRAW :8A (12V) / 4A (24V)
FUSE SIZE :15A (12V) / 8A (24V)
HOSE DIA. :1(25mm)
DELIVERY HEAD :13FT. (4M)
DIMENSION :172x128x97.1 mm

TMC-06204
Water Pumps
Description Water pump
MOTOR :12V / 24V
CAPACITY :400GPH (1512LPH)
AMP DRAW :8A (12V) / 4A (24V)
FUSE SIZE :15A (12V) / 8A (24V)
HOSE DIA. :1(25mm)
DELIVERY HEAD :13FT. (4M)
DIMENSION :172x128x97.1 mm

TMC-00006
Water Pump Pressure Switch
Description Pressure switch for 06201, 06202
PACKING :30pcs/ctn/1.62cuft
WEIGHT :8.2kgs/ctn

TMC-0621I
Water Pump Impeller
Description Replacement impeller for water pump
TMC-06201, 06202, 06203, 06204, 06205
MATERIAL :NBR ( NITRIL RUBBER )
HARDNESS :60° ± 5°0°
THICKNESS :22.1 ± 0.1mm
IMPELLER DIA :50.7mm

TMC-6010101
Electric Gear Pump
Description
Self-priming, bronze gear
Pumping elements inside
MOTOR :12V / 24V
AMP DRAW :15A (12V) / 8A (24V) FOR
GENERAL LIQUID
FUSE SIZE :35A (12V) / 15A (24V)
HOSE DIA :5/8 (16mm)
DIMENSION :161.6x183.5x171.5 mm

Specification
THREAD OPTION 1
Internal thread:1/2BSPT(w/14TPI)
External thread:3/4BSPF(w/12TPI)
ORDER NO.
503-6204011 12V
503-6204012 24V
THREAD OPTION 2
Internal thread:1/2BSPT(w/14TPI)
External thread:3/4BSPF(w/14TPI)
ORDER NO.
503-6204071 12V
503-6204072 24V

BSPT:British Standard Pipe Taper Thread
BSPF/BSPP: British Standard Pipe Parallel Thread
TPI:Thread per inch


* Todos nuestros productos gozan de 2 años de garantía.
